ZB Series Edge Folding and Rolling Machine

This machine is one part of the thermal cutting machine, it is for plastic bag edge folding and rolling.

ZB Series Edge Folding and Rolling Machine

Introduction:

This machine is one part of the thermal cutting machine, it is for plastic bag edge folding and rolling.

Features:

It is suitable for BOPP film folding with automatic gluing, organ-type bottom folding, pearl light film insert, hobbing and longitudinal sealing (used together with ultrasonic generator) and open side breaking of roll material. (The opening breaking mechanism shall be equipped separately.)

Technical Specifications:

Model

ZB-1200

ZB-1400

ZB-1600

Max. Wed width

1200mm

1400mm

1600mm

Max. Rewinding Speed

60m/min

Total Power

0.8kw

1.1kw

1.5kw

Weight

800kg

900kg

1000kg

Overall dimension

2400×1500×1500mm

2600×1500×1500mm

2800×1500×1500mm

Welcome to our website! Please feel free to send us your inquiry in detail, we will reply you as soon as possible.
