KDFQ-1300D aluminium foil slitter rewinders

This machine is used for slitting and rewinding various large rolling materials such as aluminium foil, paper,(10g/㎡-300g/㎡)cellophane paper, bill paper, OPP, PET,FILM , etc.

KDFQ-1300D aluminium foil slitter rewinders machines

Introduction:

This machine is used for slitting and rewinding various large rolling materials such as aluminium foil, paper,(10g/㎡-300g/㎡)cellophane paper, bill paper, OPP, PET,FILM , etc.

Features:

1.This machine use automatic constant tension control, central surface rewind.

2.Frequency inverter timing for main machine,keeping speedup and stable operation.

3.It has the functions of automatic metering, automatic alarm, etc.

4.Adopt up and down pneumatic shaft structure for rewinding, easy for loading and unloading.

5.It adopts photoelectric automatic error correction adjustment system for unwinding, anomalistic materials will be easy slit.(or liquid press style subtense system)

6.Equipped with automatic waste film blowing device by circle blade.

7.Automatic material inputting with pneumatic, matched with inflatable

Technical specifications:

1.Max material width:1300mm

2.Thickness of material:10g/ m2~300g/m2

3.Max diameter of raw material:φ1200mm

4. Max diameter of rewinding:φ600mm

5.Error correcting precision:±2mm

6.Precision of slitting:±0.2mm

7.Speed:10-200m/min or 300m/min(two model for choose)

8.Total power:9.5kw

9.Weight:About 3000kg
