Automatic Label Turret Rewinder
1. The turret type rewinder is equipped with an automatic paper tube mechanism, which can realize online non-stop rewinding, and can be connected with rotary die cutting and slitting machines, flexo printing machines and other equipment.
2. The rewinder is equipped with a 1-inch 1.5-inch 3-inch quick-change air shaft, which is maintenance-free for life!
3. The rewinder does not need manual mechanical adjustment when changing the size of different rewinding shafts. The system will automatically adjust according to the size of the rewinding shaft to reduce manual labor and realize intelligent production.
4. The rewinding product can be easily separated from the paper tube, and will not cause damage to the printer tape and print head to the end customer.
Main technical data：
| Model |
KSG-330 |
KSG-450 |
KSG-570 |
|
Max rewind diameter |
350mm |
350mm |
350mm |
| Max paper width |
330mm |
450mm |
570mm |
|
Max mechanical speed |
60-120M/min |
60-120M/min |
60-80M/min |
|
Max slitting strips |
5 |
5 |
5 |
| Max slitting width |
50mm |
50mm |
50mm |
|
Machine power |
8KW |
10KW |
12KW |
|
Electric |
3 Phase 380V, or special made |
||
|
Air pressure |
0.8 MPa |
0.8 MPa |
0.8 MPa |
|
Machine weight |
About 2000KG |
About 2100KG |
About 2200KG |
|
Out dimensions |
1450 x 3000 x 1700mm |
1800 x 2200 x 1800mm |
2000x 2000 x 1900mm |
Please write more details of your specific requirement, so our sales team can provide you right machine you need.
