KHZ-250 model PVC label making machine is specially for glue sealing or center gluing the PVC film material to sleeve label. This machine is widely used for making PVC label for beverage, bottle, shrink sleeve label etc.
kingsungroup
E-mail Us
PDF Download
Video Link
KHZ-250 model PVC label sleeve making machine
Introduction:
KHZ-250 model PVC label making machine is specially for glue sealing or center gluing the PVC film material to sleeve label. This machine is widely used for making PVC label for beverage, bottle, shrink sleeve label etc.
Technical specifications:
|
Model |
KHZ-250C |
KHZ-250A |
|
MAX. unwind diameter |
500mm |
500mm |
|
MAX. rewind diameter |
500mm |
500mm |
|
MAX. width of sealing |
250mm |
250mm |
|
MAX. speed of sealing |
250m/min |
300m/min |
|
Machine power |
3.5kw |
3.5kw |
|
Machine weight |
1000kg |
1000kg |
|
Overall Dimensions |
3180×1450×1550mm |
3180×1450×1550mm |
|
Features |
Man-machine interface |
|
|
Inverter speed adjust |
PLC control |
|
|
China made inverter |
Yaskawa double vector inverter |
|
|
Auto-tension for unwind and rewind |
Auto-tension for unwind and rewind |
|
|
Ultrasonic auto-web guide |
Ultrasonic auto-web guide |
|
|
Automatic meter counting |
Automatic meter counting |
|
|
Automatic gluing |
Automatic gluing |
Please write more details of your specific requirement, so our sales team can provide you right machine you need.
