MY-812 Series Lock-and-follow Dry-ink Coding Machine

The machine can be used to math with vertical and horizontal automatic packaging machine, and print the label of the product.

MY-812 Series Lock-and-follow Dry-ink Coding Machine

Product Feature

1.The machine can be used to math with vertical and horizontal automatic packaging machine, and print the label of the product.

2.It can print by solid-ink roller; the character is clear, instant printing and instant dry, with strong adhesion.

3.It can list 10 characters one line, at most 11lines.MY-821A with motor driving.

4.The print location of photo-electricity tracing can be adjustable, with accuracy.

Technical Specification

Model

MY-812G

MY-812A

Voltage (V/HZ)

AC 220V/50HZ, 110V/60HZ

Power (W)

130

150

Max. Printing Speed(pcs/min)

300

Max. Printing Line

T (10.5PT); 11Lines (Max.10 Characters/line)

R(10.5PT); 8 Lines (Max 8pcs/line)

Size of Character(Height)(mm)

2×1.5(8PT) 2.5×2(9PT) 3×3(10.5PT)

Size of Solid-ink Roller(mm)

ф35×32

Max. Horizontal Adjustable Size for Printer

 150 (Confirm When Ordering)

Weight for Printer (kg)

10

Max. Film Width (mm)

400 500 600
