KL-1040/1240 Automatic Paper Bag Making Machines

Sheet-fed, paper can be printed or non-printed.

KL-1040/1240 Model Automatic Paper Bag Making Machines

Features:

1.Sheet-fed, paper can be printed or non-printed.

2.Applicable paper: Kraft paper, art paper, duplex paper, white paperboard, gray paperboard (including laminated paper)

3.Main processes: automatic paper feeding to side guide for positioning; crease it via rolling device; then one-side gluing, tube folding & forming; bottom folding, horizontally creasing the line, bottom opening, gluing & pressing; finally output of finished bags.

Main specifications:

Model

KL-1040

KL-1240

Bag width

180-350mm

260-450mm

Bag depth

70-150mm

100-180mm

Bag length

290-600mm

380-620mm

Paper width

530-1040mm

620-1240mm

Paper length

290-600mm

380-740mm

Paper range

Kraft paper: 80-200g

art paper + PP laminated: 100-200g

white paperboard: 180-250g

gray paperboard + PP laminated: 150-250g

Speed

40-70pcs/min

40-75pcs/min

Glue type

Water glue (hot melt glue system optional for side gluing)

Total power

10kw

13kw

Weight

10T

13T

Overall dimensions (L x W x H)

13000 x 1800 x 1700mm

13300 x 2100 x 1700mm



Welcome to our website! Please feel free to send us your inquiry in detail, we will reply you as soon as possible.
